Mini Server privately deployed at the network edge, close to IoT terminals & field data sources.
The Elynkon Edge Server series is designed to bridge the divide between Operational Technology (OT) and Information Technology (IT). Each model integrates with supervisory-level devices such as HMIs, gateways, and SCADA systems, while acquiring data directly from PLCs in the control layer via protocols such as Modbus and OPC UA. By providing edge-side preprocessing, storage, and visualization, raw field data is converted into actionable insights.
Plug-and-play connection to field devices via Modbus TCP and OPC UA protocols — no complex network configuration required.
Powered by Intel Core processors, DDR4 RAM, and SSD storage — scalable configurations for every edge computing need.
Manage and access data from the cloud — monitor field operations anytime, anywhere.
Built-in charts, reports, and multi-source data support. Customize templates and branding to generate professional reports effortlessly.
Designed for Industrial IoT — data collection, processing, and visualization in one device.
📋 Pre-built variable templates for rapid, code-free batch addition of multiple devices.
📊 Multi-level grouping for control and monitoring.
💾 Local data storage with support for your own servers.
📄 Export hourly, daily, and monthly reports with custom logo and title.
⚡ Built-in edge computing scripts process data locally in real time.
🚀 No cloud latency, faster response.
🔔 Webhook-based alerts ensure immediate incident response.
✅ Keep your devices running stable.
🔒 Function-level (menu), data-level (data permissions),
👤 and management-level (admin privileges) for fine-grained control.
🔌 Native support for Modbus TCP and OPC UA industrial protocols.
🔗 Seamless integration with PLCs and automation equipment.
Detailed specifications and technical parameters for the Elynkon Edge Server series.
| Model | |
|---|---|
| Product | Edge Server I63 |
| Model | RN-ES-I63 |
| Description | Mini server integrating HMIs, gateways, and SCADA systems — with direct PLC data acquisition via Modbus TCP & OPC UA |
| System | |
|---|---|
| Processor | Intel Core i3 processor |
| OS | Linux |
| Memory | DDR4 2400MHz, 8GB |
| Storage | 1TB SSD |
| Ethernet | 2 × RJ45 10/100/1000Mbps (Realtek or Intel) |
| Video | 1 × VGA + 1 × HDMI |
| USB | 4 × USB (2 × USB 2.0 + 2 × USB 3.0) |
| Audio | 1 × Audio (Line-out / Mic-in 2-in-1) |
| WiFi | Supported |
| Mechanical | |
| Case | Single-piece aluminum alloy, custom tooling |
| Mounting | Embedded installation |
| Dimensions | 235 × 200 × 52 mm |
| Weight | 1.5 Kg |
| Environment & Power | |
| Operating Temp. | -20°C ~ 60°C |
| Storage Temp. | -30°C ~ 70°C |
| Humidity | 5% ~ 95%, Non-condensing |
| Power Input | DC 12V@5A |
Documentation and online help resources for the Elynkon AIoT products.
Complete product overview, specifications, and features for the I63 model.
⬇ DownloadStep-by-step installation, configuration, and usage guide for the I63 model.
⬇ DownloadComprehensive documentation for the AIoT Center platform, including device management, alarm monitoring, task automation, and data visualization.
